The challenge
What needed to change
Manual machining estimates can require repeated geometry review and calculations, making quote preparation time-consuming and inconsistent.
← Back to projects
Manufacturing TechnologyAutomated Machining Cost Estimation
Estimate.ae
A custom estimation platform with built-in logic that calculates machining costs automatically from .STP files.
●Project case study
PROJECT SHOWCASE
Estimate.ae
⬆
.STP
CAD File Input
⌘
Rule-based
Cost Estimation
✓
Consistent
Quote Workflow
Project overview
Understanding the bigger picture
A specialized estimation workflow that uses geometry information from .STP files and configured pricing rules to help generate machining cost estimates.
Our approach
A practical solution
Combine file upload, geometry extraction, configurable costing rules, and quote generation in one workflow. Final estimates should be validated by manufacturing specialists.
Key highlights
Designed around what matters
Explore the core capabilities behind the project.
📁01
CAD File Upload
Accept supported .STP files as the starting point for estimation.
📐02
Geometry Extraction
Read geometry details required by configured costing logic.
🧮03
Cost Calculation
Apply material, process, and pricing rules to estimate costs.
🧾04
Quote Generation
Present calculated estimates in a clear quote workflow.
Capabilities
Features built for real workflows
Explore the functionality and capabilities that power this solution.
01
Estimation Features
- ✓Upload supported .STP files
- ✓Extract relevant geometry information
- ✓Apply configurable machining cost logic
- ✓Support material and process pricing rules
- ✓Generate consistent estimate outputs
02
Workflow Management
- ✓Review uploaded file details
- ✓Configure estimation parameters
- ✓Track estimate status
- ✓Review generated quote information
- ✓Reduce repeated manual calculation steps
Problem solving
From challenges to solutions
Discover how the solution addresses practical challenges.
Challenge 01
Manual Geometry Review
Cost estimators repeatedly inspect CAD files to identify relevant details.
Our solution
Geometry Extraction
Extract supported geometry information from uploaded files.
✓ More structured estimation input
Challenge 02
Inconsistent Calculations
Different manual approaches can produce varying estimates.
Our solution
Configured Cost Rules
Apply defined pricing and process rules consistently.
✓ More repeatable calculations
Challenge 03
Slow Quote Preparation
Preparing estimates can involve several disconnected steps.
Our solution
Unified Estimate Workflow
Connect file input, calculation, and quote output.
✓ A more streamlined quoting process
Engineering workflow
Technology Stack
Replace generic stack categories with the confirmed implementation details.
File Processing
CAD input and geometry information
box
STEP / STP Processing
Read supported CAD geometry data
CADGeometry
Costing Engine
Configured rules and estimate output
calculator
Costing Logic
Apply material, process, and pricing rules
RulesEstimation
database
Estimate Records
Store and review quote information
QuotesHistory
Delivery process
Project Timeline
A sample delivery sequence for a custom estimation platform.
01Phase 1
Costing Discovery
Understand supported files and estimation rules.
- •Review STP samples
- •Map costing parameters
- •Define expected outputs
02Phase 2
File Processing
Build upload and geometry extraction workflows.
- •File validation
- •Geometry extraction
- •Parameter mapping
03Phase 3
Cost Engine & QA
Implement costing rules and verify sample estimates.
- •Cost calculations
- •Quote generation
- •Expert validation
04Phase 4
Deployment
Prepare the workflow for operational use.
- •User acceptance testing
- •Deployment checks
- •Documentation
Project Demo
See the Project in Action
Watch the project preview below. Login to access the complete video.
Want to Watch the Full Video?
Login to explore the complete project walkthrough.
Project outcomes
Built to make work clearer
Key outcomes and improvements delivered through the project.
- ✓More structured CAD-to-estimate workflow
- ✓Repeatable application of configured costing rules
- ✓Clearer estimate review and quote preparation
